In June 2020 INFO  TECH has released a new version of 61850 Avenue toolset with new capabilities.

The client tool:

- supports secure connections using TLS,

- allows to search for specified objects of the server,

- offers an improved generation of an ICD file from the information explored from a server device.

GOOSE and SV toolsets allow to communicate not only over Ethernet network but also using routable communication over IP protocol.

Welcome to learn the details of the new release of the 61850 Avenue toolset.

INFO TECH testing and simulation tools for the IEC 61850 standard based communication are already licensed to over 100 companies and research institutions from 5 continents.

In April 2020 INFO TECH releases a new tool for testing and diagnosing the IEC 61850 communication - 61850 GOOSE System Viewer.

The program allows to import an SCD file (System Configuration Description) and visualize all configured GOOSE data flows among devices in the graphical connection diagram. In case of a large system the connection diagram may not fit to a single screen but the tool allows for an easy navigation in the context of any data flow: to a chosen IED, a chosen source data or a chosen destination.

GOOSE data flow can be also presented in the form of a list of all outgoing and all incoming data - with the possibility to use IED filters on both ends. The produced list can be exported into a text file.

61850 GOOSE System Viewer can be used for online monitoring of GOOSE communication in the running installation. In online mode the connections on the diagram and the transmissions in the list are marked with colors that describe whether:

• GOOSE transmission proceeds correctly with source and destination data marked with green background,
• GOOSE transmission has stopped (old data),
• an erroroneus frame has been detected,
• there is no transmission,

while any selected connection is distinguished with blue color.

The tool allows also to set up the monitoring for two additional views: the list of events (changes of data in GOOSE messages) and the list of alarms (based on user defined conditions on data in GOOSE messages).

61850 GOOSE System Viewer will be offered as an optional program to 61850 Avenue toolset (extended license price).

Presentation material of the 61850 GOOSE System Viewer tool  (także wersja polska)

Leaflets of 61850 GOOSE System Viewer

Special discount to schools and universities.

Please This email address is being protected from spambots. You need JavaScript enabled to view it. for additional information.

In April 2020 INFO TECH has released a new version of 61850 SCL Runner toolset with extended simulation capabilities.

The toolset allows to use multiple network adapters with the possibility to assign a selected adapter to each IED before starting its simulation.

It is also possible to drive the simulation from the user defined program - using telnet communication with 61850 SCL Runner tool. Hence there is no need to learn any proprietary script language but just the syntax of few types of commands used over telnet. The installation package includes an example program (in Python) for driving the simulation process.

Welcome to learn the details of the new release of 61850 SCL Runner.

INFO TECH testing and simulation tools for the IEC 61850 standard based communication are already licensed to over 100 companies and research institutions from 5 continents.

In February 2020 the IEC published new documents of the IEC 61850 standard - the new releases of parts 7-2, 7-3, 7-4, 8-1 and 9-2 appeared as Edition 2.1 (part 6 in Edition 2.1 was published already in 2018).

But Edition 2.1 shall not be treated as a new edition of the standard - formally and essentially this is Amendment 1 to Edition 2 (in short Am.1 Ed.2), which supersedes the former publications of the IEC 61850 standard Edition 2.

What comes to conformance testing in accordance with the procedures specified by the UCA International Users Group, please note that the latest published Ed.2 Server Test Procedures (version 2.0.1) and Client Test Procedures (version 1.1.1.) already incorporate a big subset of tissues included in the IEC 61850 Am.1 Ed.2. These test procedures will remain in use (without changes) until Am.1 Ed.2 Test Procedures are prepared and published (which is expected in Q4 2020). As a consequence, please be aware that by mid 2021 the testing of conformance to Edition 2 will finally become exclusively based on the IEC 61850 Am.1 Ed.2.

In March 2020 INFO TECH has already accomplished a detailed analysis of changes and extensions to the IEC 61850 standard brought by the published Am.1 Ed.2.  Thus, we can assure that already in this year we will be able to support our customers-licensees with the updated source code of INFO TECH IEC61850 Software Library and with the updated toolsets for communication testing and simulation.

If one wonders whether Edition 2.1 is backward compatible with the former Edition 2 - the answer is the same as before with Edition 2 following Edition 1 of the IEC 61850 standard: unfortunately not in some still essential elements ...

Please This email address is being protected from spambots. You need JavaScript enabled to view it. in case of aiming to be a front-runner in your products and systems adaptation to the latest version of the IEC 61850 standard - we will help you to leave your competitors behind.

Quoting Seneca: "Luck is what happens when preparation meets opportunity".
